Mr12Volt Jaguar XF, XFR, XK, XKR - High End Audio MOST Bus CarPlay & AA Interface OEM mic support

In stock
SKU: P2000-XF09MM
Regular price £375.00 inc. VAT

High End Audio MOST Bus CarPlay & Android Auto Interface with OEM Microphone Support

Model No: P2000-XF09MM
The brand new Mr12Volt P2000 MM series has just gotten better now with built in DSP and OEM microphone support.

Compatible with the following Jaguar:

Jaguar XF / XFR      2008 - 2011 ( Pre-facelift )

Jaguar XK / XKR     2007 - 2015

IMPORTANT: The P2000 will replace the OEM USB module.

Installation videos:

Highlight Features:

  • OEM microphone support
  • Runs on MOST BUS with High-End audio quality
  • Wireless & Wire Apple CarPlay, Google Android Auto
  • Wireless MirrorLink
  • Bluetooth Handsfree & Audio Streaming
  • USB Video & Music Playback
  • Reverse / Front / Left or Right Camera Input
  • Supports Apple Lossless Music Streaming
  • Highly Customisable 15 Bars DSP Equaliser

How it works

  • Mr12volt is selected through Portable Audio > USB features of the head unit
  • No coding is needed
  • Supports aftermarket cameras up to AHD720

    P2000 supported multimedia type (High performance video and audio codec)

    • Decoding H.264 (Baseline and Main High Profile, Level 1-4.2)  30fps @1080p
    • Decoding VC-1 (Simple Main Profile, low, medium and high levels. Advanced Profile, levels 0-3) 30fps @1080p
    • Decoding MPEG1/2/4 (Simple Profile, levels 0-6. Main Profile, low, medium andhigh levels. ASP, levels 0-5) 30fps @1080p
    • Decoding Real-Video 8/9/10 30fps @1080p
    • Decoding VP6/7/8 (VP6.0/1/2, VP7 version 0-3, VP8 version 2(WebM)) 30fps @1080p
    • Decoding DivX (DivX3/4/5/6) 30fps @1080p
    • Decoding H.263 (Profile 0, levels 10-70.) 30fps @720x576
    • JPEG codec (Baseline interleaved) 8176x8176
    • Support *.mkv, *.mp4, *.avi, *.wmv, *.rmvb, *.rm, *.mpg, *.mpeg, *.ts, *.dat, *.asf, *.flv, *.vob, and so on file format
    • Multi Format Audio CODEC (MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR, and so on)

    Related Topics:

    How to mirror to P2000 from phone

    Additional Technical Data:

    • Operating Temperature: -20 - +80 degree centigrade
    • DAC resolution: 18Bit
    • MP3 kbit: 8 - 384kbit
    • Voltage: 10 - 14.6V DC
    • Operation Current: 450mA (700mA when charging mobile phone)
    • S/N ratio: 95dB
    • Total Harmonic Distortion: 0.1%
    • Frequency Response: 20Hz - 20KHz
