High End Mercedes Benz CarPlay & Android Auto Interface

Model No: P2000-NTG45MM

Brief introduction

(Unlike other products that use "AUX in" as an audio source which downgrades the audio quality)
Mr12volt uses the MOST optical system and utilises "TV" video input, therefore providing a high end digital to digital sound quality. If you have a Harmon Kardon or high sound system, Mr12volt is your choice!!

No hassel to look for Coding !!
Mr12volt Module comes with a Built-In TV enabling function with NO third party coding tools required

And how do i activate TV function with Mr12volt??
After installing Mr12volt, simply press "C" + Return" buttons together for 5 secs, TV Menu will appear immediately

Compatible with Mercedes-Benz NTG 4.5 / 4.7 2012-2015

W212 A207 C207 E-class
W204 C
W176 A
W246 B
C218 CLS
W166 ML
X166 GL
W463 G
R172 SLK
R231 SL
C197/R197 SLS

Highlight Features:

OEM microphone supported
Runs on MOST BUS with High-End sound quality
Supports OEM Reverse Camera
Possible to add Aftermarket Front/Reverse/Blind spot Cameras
Wireless & Wired Apple CarPlay, Google Android Auto
Wireless MirrorLink
Bluetooth Hands free & Audio Streaming
USB Video & Music Playback
Supports Apple Lossless music streaming
Highly Customisable 15 bar DSP Equalizer

How it works

Mr12volt is selected through TV features of Mercedes NTG 4.5 / 4.7
No coding tools or Factory TV module is needed, once Mr12volt CarPlay module is installed successfully (pressing both "Return" and "C" buttons will activate the "TV" option in menu)
Supports aftermarket cameras up to AHD720
Supports the integration of OEM microphone
Both MB and Mr12volt Bluetooth can be connected at the same time. MB will handle as HF/call and Mr12volt as HF/Media (as a result, MB HF takes over Mr12volt when a call is received)

P2000 supported multimedia type

High performance video and audio codec

Decoding H.264 (Baseline and Main High Profile, Level 1-4.2) 30fps @1080p
Decoding VC-1 (Simple Main Profile, low, medium and high levels. Advanced Profile, levels 0-3) 30fps @1080p
Decoding MPEG1/2/4 (Simple Profile, levels 0-6. Main Profile, low, medium and high levels. ASP, levels 0-5) 30fps @1080p
Decoding Real-Video 8/9/10 30fps @1080p
Decoding VP6/7/8 (VP6.0/1/2, VP7 version 0-3, VP8 version 2(WebM)) 30fps @1080p
Decoding DivX (DivX3/4/5/6) 30fps @1080p
Decoding H.263 (Profile 0, levels 10-70.) 30fps @720x576
JPEG codec (Baseline interleaved) 8176x8176
Support *.mkv, *.mp4, *.avi, *.wmv, *.rmvb, *.rm, *.mpg, *.mpeg, *.ts, *.dat, *.asf, *.flv, *.vob, and so on file format
Multi Format Audio CODEC (MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR, and so on)
