Mr12Volt Porsche 911, Boxster, Cayman - High-End Porsche PCM 3.0 MOST Bus CarPlay & AA Interface OEM mic support

In stock
SKU: P2000-PCM30MM
£416.00 inc. VAT
Description

MOST Bus CarPlay & Android Auto Interface

Model No: P2000-PCM30MM
The brand new Mr12Volt P2000 MM series has just gotten better now with OEM microphone support.


Compatible with PCM 3.0 on the following Porsches:

911                              2009 - 2011
Cayenne                    2009
Boxster/Cayman     2009-2012

IMPORTANT:

If the Porsche has OEM TV built in, we suggest not to purchase this product right now as the OEM rear camera will not function properly. Please wait for future updated product.

For base audio (no FO cable in car's harness) Porsche please follow this video to modify the supplied FO Y cable to a direct male to male cable:



Highlight Features:

  • Supports OEM microphone
  • Runs on MOST BUS with High-End sound quality
  • Wireless & Wired Apple CarPlay, Google Android Auto
  • Wireless MirrorLink
  • Bluetooth Hands free & Audio Streaming
  • USB Video & Music Playback
  • Reverse / Front / Left or Right camera Input
  • Supports Apple Lossless music streaming
  • Highly Customizable 15 bar DSP Equalizer

How it works

  • Mr12volt is selected through TV features of PCM
  • No coding or Factory TV module is needed, once Mr12volt CarPlay module is installed successfully, the "TV" icon will appear on the PCM home menu right away.
  • Supports aftermarket cameras up to AHD720

    P2000 supported multimedia type (High performance video and audio codec)

    • Decoding H.264 (Baseline and Main High Profile, Level 1-4.2)  30fps @1080p
    • Decoding VC-1 (Simple Main Profile, low, medium and high levels. Advanced Profile, levels 0-3) 30fps @1080p
    • Decoding MPEG1/2/4 (Simple Profile, levels 0-6. Main Profile, low, medium andhigh levels. ASP, levels 0-5) 30fps @1080p
    • Decoding Real-Video 8/9/10 30fps @1080p
    • Decoding VP6/7/8 (VP6.0/1/2, VP7 version 0-3, VP8 version 2(WebM)) 30fps @1080p
    • Decoding DivX (DivX3/4/5/6) 30fps @1080p
    • Decoding H.263 (Profile 0, levels 10-70.) 30fps @720x576
    • JPEG codec (Baseline interleaved) 8176x8176
    • Support *.mkv, *.mp4, *.avi, *.wmv, *.rmvb, *.rm, *.mpg, *.mpeg, *.ts, *.dat, *.asf, *.flv, *.vob, and so on file format
    • Multi Format Audio CODEC (MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR, and so on)

    Related Topics:

    How to mirror to P2000 from phone

    Additional Technical Data:

    • Operating Temperature: -20 - +80 degree centigrade
    • DAC resolution: 18Bit
    • MP3 kbit: 8 - 384kbit
    • Voltage: 10 - 14.6V DC
    • Operation Current: 450mA (700mA when charging mobile phone)
    • S/N ratio: 95dB
    • Total Harmonic Distortion: 0.1%
    • Frequency Response: 20Hz - 20KHz
